HZS120 Stationary Concrete Batching Plant
-
Productivity: 120m3/h
-
Capacity of Mixer: 2m3
-
Discharge Height: 3.8m
-
Feeding Type: Belt
- Description
- Parameter
- Drawing
- Inquiry
1. Description of HZS120 Concrete Batching Plant :
HZS120 concrete batching plant is suitable for large construction, precast factory and commercial concrete production plant.All the parts can be installed and disassembled easily, each layer of the packaging side can be opened which is convenient for maintenance and replacement parts.All materials scale adopts independent measurement, a scale of a table, which improves the measurement precision of aggregate lifting belt;
2. The Features of HZS120 Concrete Batching Plant:
1. Modular design structure, which is easy to install and disassemble
2. With JS3000 twin shaft compulsory concrete mixer, which has the high productivity and good mixing performance.
3. Suitable large size construction projects, eg, bridge, dam, road, school buildings,etc.
4.Good choice for commercial concrete
5.Control components are importing from USA, Japan, Germany.
Specification | Unit | Value |
---|---|---|
Productivity | m3/h | 120 |
Capacity of Mixer |
m3 | 2 |
Discharge Height |
m | 3.8 |
Aggregate Bin |
Quantity | 4 |
Capacity of Aggregate Bin |
m3 | 20 |
Max. Weighing Value of aggregate |
kg | 2x4000 |
Max. Weighing Value of cement |
kg | 1800 |
Max. Weighing Value of water |
kg | 800 |
Max. Weighing Value of additive |
kg | 50 |
Feeding Type | / | Belt |
Cement Silo | / | Optional |
Cement Screw Conveyor | / | Optional |
Control Mode | / | Auto Control |
