JS2000 Concrete Mixer

Mixer Capacity: 2.0m3
Discharging Volume: 2000L
Charging Volume: 3000L
Mixer Motor Power: 2x37kw

Share with:

Parameter
Drawing
Inquiry

1. Description of JS2000 Concrete Mixer:

JS 2000 concrete mixer has a rational design structure with new arrangement, and is easy to be repaired and used. JS 2000 concrete mixer is composed of double shaft compulsory concrete mixer.

2. The Advantages of JS2000 concrete mixer:

1. To be operated independently as single

2. To be combined with PLD series compounding machine to form simple concrete batching plant

3. To provide associated main machine for batching plant

4. To be applicable to large, medium and small scale prefabricated components plants and road, bridge, irrigation works, dock and civil building project

5. To mix hard concrete, quaking concrete, fluidity concrete, light weight aggregate concrete and various kinds of high efficiency model.

3. The features of JS2000 Concrete Mixer:

1. Excellent mixing performance

2. Wear-resisting lining board

3. Shaft-end sealing technology

4. Multiple protection devices

Specification	Unit	Value
Discharging Volume	L	2000
Charging Volume	L	3000
Mixing Capacity	m3	2
Aggregate Size	mm	80/100
Working Circle	sec	30
Mixer Motor Power	kw	2x37
Weight	kg	7500
Dimensions	mm	3460x2320x2140
