35m3/h Mini Mobile Concrete Batching Plant
2026.06.17
In equipment selection for small and medium-sized infrastructure projects, overcapacity can lead to idle and wasted investment, while insufficient capacity will directly slow down the construction period. A 35m³/h mini mobile concrete batching plant strikes the perfect balance between "sufficient capacity, flexibility, and low cost." The Haomei Machinery YHZS35 mini mobile concrete batching plant, with its stable rated capacity of 35 cubic meters per hour, integrated trailer design, and precise graded metering system, has become a primary choice for rural infrastructure, road repair, small-scale municipal projects and emergency repairs. It is also one of the most purchased lightweight models by overseas small and medium-sized project customers.
As the standard configuration of a 35 cubic meter mini mobile concrete batching plant, the YHZS35 concrete batching plant is equipped with a JS750 twin-shaft forced concrete mixer with a nominal discharge volume of 750L. A single mixing cycle takes approximately 60 seconds, resulting in a theoretical production rate of 35 m³/h. Under continuous and stable operation, the production capacity remains at 30–32 m³/h, producing 240–260 cubic meters of finished concrete in an 8-hour shift, fully covering the daily construction needs of most small and medium-sized projects. The main unit liner and mixing blades are made of high-manganese wear-resistant material, with a service life of over 80,000 batches under normal operating conditions. It is suitable for crushed stone with a particle size ≤60mm and gravel aggregate ≤80mm, producing both ordinary plastic concrete and stable mixing of dry-hard and semi-dry-hard concrete, adapting to the mix proportion requirements of various projects such as building construction, road and bridge construction, and water conservancy.
Rapid deployment and flexible relocation are the core structural advantages of the YHZS35 concrete batching plant. The entire machine adopts a single-trailer chassis integrated design, integrating the aggregate batching bin, belt conveyor system, mixing host, weighing unit, and electrical control cabinet onto a single frame. All components are pre-tested and debugged before leaving the factory, and all pipelines and lines have pre-designed quick-connect structures, eliminating the need for on-site assembly. The equipment requires no dedicated concrete foundation; only a leveled and hardened ground surface is needed for placement. Leveling is achieved via hydraulic outriggers. The entire process from equipment arrival to power-on operation takes no more than 24 hours, saving over 70% of the construction period and civil engineering costs compared to a stationary concrete batching plant of the same capacity. During relocation, there is no need to disassemble core components; movement is achieved simply by connecting a trailer with a towing pin. Road towing speeds reach up to 40 km/h, and the machine's dimensions are compatible with standard containers, making cross-border sea freight and inland transshipment highly convenient.
In terms of metering accuracy and control performance, the YHZS35 mini mobile concrete batching plant adopts a graded independent weighing system. The aggregate end is equipped with a PLD1200 concrete batching machine, supporting cumulative metering of 3-4 types of aggregates with a weighing accuracy controlled within ±2%. Cement, water, and admixtures each have independent weighing units, with powder and liquid metering accuracy reaching ±1%, enabling precise proportion control and ensuring the stability of the finished concrete strength. The control system comes standard with a PLC and touchscreen human-machine interface, supporting switching between fully automatic continuous production and manual fine-tuning modes. It has built-in fault self-diagnosis, production data recording, and report printing functions. The operating logic is clear, and ordinary operators can operate independently after short-term training. Multilingual operating interfaces can also be customized according to the needs of overseas customers.
From a project investment perspective, the value of the 35m3/h mini mobile concrete batching plant lies not only in the equipment itself but also in its extremely low implementation cost and multi-scenario reusability. Weighing approximately 18 tons, the machine has low requirements for site load-bearing capacity and can be quickly put into operation in mountainous and rural areas with weak infrastructure. Equipped with a pulse dust collector and a closed silo structure, its dust emissions meet general environmental standards, making it suitable for construction in suburban areas. Compared to stationary concrete batching plant equipment, its ability to be moved and reused across projects significantly reduces the investment per project, making it particularly suitable for multi-section, short-cycle, and decentralized small and medium-sized infrastructure projects. It is a high-performance, cost-effective choice that balances capacity, flexibility, and economy.
